Mitutoyo Dial Gage 2929s

Mitutoyo Dial Gage 2929s

Price :
₹ 5442.00
GST inclusive
Code:
Quantity:
Add to Cart

Order No.

Graduation

Range

(range/Rev)

Maximum  permissible

error (MPE) (µm)

Dial

reading

Measuring

force (N)

Indication error

Hysteresis

Repeatability

1/10

rev

1/2

rev

1

rev

Measuring

range

2929S

0.01mm

0.8(1)mm

5

_

_

8

3

3

40-0-40

1.4 or less



  • Mitutoyo's unique shock-proof mechanism is incorprated, providing improved resistance to shock due to sudden spindle retraction caused by impact.
  • This series has been developed to eliminate the possibility of reading error due to miscounting multiple revolutions.
  • All types come with limit markers and a bezel clamp.
  • The bezel clamp and lifting lever (optional) can be attached to either the light or left side. these parts can be easily installed and removed without tools.
  • The stem and spindle are made of highly-strength quench-hardened stainless steel suitable for heavy duty use.
  • A carbide contact point is used
  • Application of a hard coating on the surface of the crystal makes the gage highly scratch-and chemical-resistant
  • The dead zone in red indicates "accuracy not guaranted"
