Mitutoyo Digital Disk Micrometer 323 Series

Mitutoyo Digital Disk Micrometer 323 Series

Price :
₹ 30997.00
GST inclusive
Code:
Quantity:
Add to Cart

Order No.

Range(mm)

Resolution

Maximum permissible

Error JMPE (µm)

Anvil dia

Measurable

module

323-251

25-50mm

0.001mm

±4

Ø20mm

0.5-6



  • Measures "root tangent length" of spar gear and helical gears
  • Determination of quick guide to precision measuring instruments"
  • Equipped with ratchet stop for constant measuring force.
  • Supplied with a setting standard (except for 0 to 25mm/0 to1inch measuring range)
  • Measuring surfaces are constructed of carbide to reduce wear
  • IP65 protection enables use in environments exposed to cutting oil, coolant, dust, etc., for most shop floor environments
  • Ratchet mechanism provides an audible click to ensure measurement is performed with constant force
  • SPC output function allows for quick and easy data management in real time
  • Functions include Origin Set, Zero/ABS Setting, Data Hold, Data Output, Function Lock, and inch/mm conversion (on inch/metric models only)
  • Alarm: Low Voltage, Counting Value Composition Error
  • Satin chrome finish on the sleeve and laser etched measurements on thimble for easier reading
  • Frame has a non-slip finish for better grip in shop environments
