Model |
Clamping Height range |
Suitable for T-slot size |
Tightening Torque Nm Max |
Clamping force Max |
N.W kgs |
|
CMC-12 |
0-125 |
12 |
70 |
1600kg |
2.0 |
|
CMC-14 |
0-125 |
14 |
70 |
1600kg |
2.0 |
|
CMC-16 |
0-125 |
16 |
70 |
1600kg |
2.0 |
|
CMC-18 |
0-125 |
18 |
70 |
1600kg |
2.1 |
Compact milling clamp is the most multipurpose quick and easy to use down hold milling clamp. it is equally suitable for clamping while all kinds of machining operation on drilling, milling, machining centre, EDM etc. this clamp does not require any support blocks or any kind of adjustment, clamping is done by simple turning of the removable spanner key.
